Telemecanique Sensors XS618B1PAL2 Nicht kategorisiert
MPN: XS618B1PAL2
Quickcode: B51256307
(Telemecanique Proximity Sensor)
Hinweis: Die Bildgenauigkeit kann nicht garantiert werden. Bitte verlassen Sie sich bei Ihrer Kaufentscheidung nicht ausschließlich auf das Bild.
€46.78
€55.67 inkl. MwSt.
Alle Produkte auf dieser Website sind in der EU zollfrei erhältlich
Businesskunden zahlen keine Mwst. - Verifizieren Sie es hier
Businesskunden zahlen keine Mwst. - Verifizieren Sie es hier
Quickcode:
B51256307
MPN:
XS618B1PAL2
Hersteller:
telemecanique
EAN:
💰 Erhalten Sie Cash Back bei Zahlung per Debitkarte oder Banküberweisung!
Hinweis: Die folgenden Informationen dienen lediglich Ihrer Information und wir können keine Gewähr für ihre Richtigkeit übernehmen. Bitte überprüfen Sie die Angaben gegebenenfalls vor dem Kauf mit uns.
Telemecanique Sensors XS618B1PAL2 not categorizedInductive Threaded Barrel Proximity Sensor, M18, 8 mm Detection, PNP NO, 12 - 48 V dc
Telemecanique Inductive Proximity Sensors OsiSense XS.Telemecanique Inductive Proximity Sensors OsiSense XS series (extended sensing range) allow you to detect all types of objects in all applications providing high detection performance for metal objects. This inductive sensor range with industry recognised high performing technology provide non-contact detection of material up to 20 mm. Inductive proximity sensors are available in flush and non-flush models (shielded and non-shielded).
OsiSense inductive proximity sensors are purely for detecting any metal objects up to 60 mm and include an oscillator with windings (an alternating magnetic field is generated in front) making up the sensing phase.
Styles Available.
Flush and Non-Flush (shielded and non-shielded).
Flat form.
Short and long body.
PNP and NPN versions (compatible with PLCs and controllers).
2 Wire DC, AC or AC/DC versions (available to be installed as a limit switch).
How do they work and where can I use them?
Inductive proximity sensors contain a coil and an oscillator, these create an electromagnetic field close to the sensing surface. When metal enters this field, a change occurs in the oscillating amplitude. This, in turn, changes the sensor output, showing you and equipment that metal has been sensed. Inductive proximity sensors are suitable for use most industries. Inductive sensors are unaffected by oil, dirt or surface finish and can be used in high vibration and high shock areas.
Applications.
Railway. Mobile equipment. Lists and escalators. Hoisting. Material handling, conveying, logistics.
Material working, machine tools. Packaging. Food and beverage. Robotics.
XS618B1PAL2 Telemecanique Inductive Proximity Sensor.
OsiSense XS6.
General purpose.
Cylindrical M18 (1 pin).
62 mm.
Fixed body.
Flush mount.
Metal Nickel plated brass.
Front material PPS.
Discrete signal.
3-Wire.
8 mm nominal sensing distance.
1 NO.
Output circuit DC.
Discreet output PNP.
Cable connection (2 m).
Threaded length 52 mm.
Length 62 mm.
Weight 0.12 kg.
Protection.
IP68 Double insulation to IEC 60529
IP 69K to DIN 40050.
Certification.
CSA, UL, E2.
